sgmm2-est-fmllr.cc File Reference
#include <string>
#include <vector>
#include "base/kaldi-common.h"
#include "util/common-utils.h"
#include "sgmm2/am-sgmm2.h"
#include "sgmm2/fmllr-sgmm2.h"
#include "hmm/transition-model.h"
#include "hmm/posterior.h"
Include dependency graph for sgmm2-est-fmllr.cc:

Go to the source code of this file.

Namespaces

 kaldi
 This code computes Goodness of Pronunciation (GOP) and extracts phone-level pronunciation feature for mispronunciations detection tasks, the reference:


Functions

void AccumulateForUtterance (const Matrix< BaseFloat > &feats, const Matrix< BaseFloat > &transformed_feats, const std::vector< std::vector< int32 > > &gselect, const Posterior &post, const TransitionModel &trans_model, const AmSgmm2 &am_sgmm, BaseFloat logdet, Sgmm2PerSpkDerivedVars *spk_vars, FmllrSgmm2Accs *spk_stats)

int main (int argc, char *argv[])


Function Documentation

◆ main()

int main ( int  argc,
char *  argv[]
)

Definition at line 69 of file sgmm2-est-fmllr.cc.

References kaldi::AccumulateForUtterance(), kaldi::ApplyAffineTransform(), AmSgmm2::ComputePerSpkDerivedVars(), MatrixBase< Real >::CopyFromMat(), SequentialTableReader< Holder >::Done(), AmSgmm2::FeatureDim(), ParseOptions::GetArg(), RandomAccessTableReader< Holder >::HasKey(), rnnlm::i, FmllrSgmm2Accs::Init(), RandomAccessTableReader< Holder >::IsOpen(), KALDI_ERR, KALDI_LOG, KALDI_WARN, SequentialTableReader< Holder >::Key(), SequentialTableReader< Holder >::Next(), ParseOptions::NumArgs(), AmSgmm2::NumGauss(), MatrixBase< Real >::NumRows(), ParseOptions::PrintUsage(), MatrixBase< Real >::Range(), Sgmm2FmllrGlobalParams::Read(), ParseOptions::Read(), TransitionModel::Read(), AmSgmm2::Read(), Sgmm2FmllrConfig::Register(), ParseOptions::Register(), Sgmm2PerSpkDerivedVars::SetSpeakerVector(), MatrixBase< Real >::SetUnit(), FmllrSgmm2Accs::SetZero(), Input::Stream(), FmllrSgmm2Accs::Update(), RandomAccessTableReader< Holder >::Value(), SequentialTableReader< Holder >::Value(), and TableWriter< Holder >::Write().

69  {
70  try {
71  typedef kaldi::int32 int32;
72  using namespace kaldi;
73  const char *usage =
74  "Estimate FMLLR transform for SGMMs, either per utterance or for the "
75  "supplied set of speakers (with spk2utt option).\n"
76  "Reads state-level posteriors. Writes to a table of matrices.\n"
77  "--gselect option is mandatory.\n"
78  "Usage: sgmm2-est-fmllr [options] <model-in> <feature-rspecifier> "
79  "<post-rspecifier> <mats-wspecifier>\n";
80
81  ParseOptions po(usage);
82  string spk2utt_rspecifier, spkvecs_rspecifier, fmllr_rspecifier,
83  gselect_rspecifier;
84  BaseFloat min_count = 100;
85  Sgmm2FmllrConfig fmllr_opts;
86
87  po.Register("spk2utt", &spk2utt_rspecifier,
88  "File to read speaker to utterance-list map from.");
89  po.Register("spkvec-min-count", &min_count,
90  "Minimum count needed to estimate speaker vectors");
91  po.Register("spk-vecs", &spkvecs_rspecifier,
92  "Speaker vectors to use during aligment (rspecifier)");
93  po.Register("input-fmllr", &fmllr_rspecifier,
94  "Initial FMLLR transform per speaker (rspecifier)");
95  po.Register("gselect", &gselect_rspecifier,
96  "Precomputed Gaussian indices (rspecifier)");
97  fmllr_opts.Register(&po);
98
99  po.Read(argc, argv);
100
101  if (po.NumArgs() != 4) {
102  po.PrintUsage();
103  exit(1);
104  }
105
106  string model_rxfilename = po.GetArg(1),
107  feature_rspecifier = po.GetArg(2),
108  post_rspecifier = po.GetArg(3),
109  fmllr_wspecifier = po.GetArg(4);
110
111  TransitionModel trans_model;
112  AmSgmm2 am_sgmm;
113  Sgmm2FmllrGlobalParams fmllr_globals;
114  {
115  bool binary;
116  Input ki(model_rxfilename, &binary);
117  trans_model.Read(ki.Stream(), binary);
118  am_sgmm.Read(ki.Stream(), binary);
119  fmllr_globals.Read(ki.Stream(), binary);
120  }
121  if (gselect_rspecifier == "")
122  KALDI_ERR << "--gselect option is required.";
123
124  RandomAccessPosteriorReader post_reader(post_rspecifier);
125  RandomAccessBaseFloatVectorReader spkvecs_reader(spkvecs_rspecifier);
126  RandomAccessInt32VectorVectorReader gselect_reader(gselect_rspecifier);
127  RandomAccessBaseFloatMatrixReader fmllr_reader(fmllr_rspecifier);
128
129  BaseFloatMatrixWriter fmllr_writer(fmllr_wspecifier);
130
131  int32 dim = am_sgmm.FeatureDim();
132  FmllrSgmm2Accs spk_stats;
133  spk_stats.Init(dim, am_sgmm.NumGauss());
134  Matrix<BaseFloat> fmllr_xform(dim, dim + 1);
135  BaseFloat logdet = 0.0;
136  double tot_impr = 0.0, tot_t = 0.0;
137  int32 num_done = 0, num_err = 0;
138  std::vector<std::vector<int32> > empty_gselect;
139
140  if (!spk2utt_rspecifier.empty()) { // per-speaker adaptation
141  SequentialTokenVectorReader spk2utt_reader(spk2utt_rspecifier);
142  RandomAccessBaseFloatMatrixReader feature_reader(feature_rspecifier);
143
144  for (; !spk2utt_reader.Done(); spk2utt_reader.Next()) {
145  spk_stats.SetZero();
146  string spk = spk2utt_reader.Key();
147  const vector<string> &uttlist = spk2utt_reader.Value();
148
149  Sgmm2PerSpkDerivedVars spk_vars;
150  if (spkvecs_reader.IsOpen()) {
151  if (spkvecs_reader.HasKey(spk)) {
152  spk_vars.SetSpeakerVector(spkvecs_reader.Value(spk));
153  am_sgmm.ComputePerSpkDerivedVars(&spk_vars);
154  } else {
155  KALDI_WARN << "Cannot find speaker vector for " << spk;
156  num_err++;
157  continue;
158  }
159  } // else spk_vars is "empty"
160
161  if (fmllr_reader.IsOpen()) {
162  if (fmllr_reader.HasKey(spk)) {
163  fmllr_xform.CopyFromMat(fmllr_reader.Value(spk));
164  logdet = fmllr_xform.Range(0, dim, 0, dim).LogDet();
165  } else {
166  KALDI_WARN << "Cannot find FMLLR transform for " << spk;
167  fmllr_xform.SetUnit();
168  logdet = 0.0;
169  }
170  } else {
171  fmllr_xform.SetUnit();
172  logdet = 0.0;
173  }
174
175  for (size_t i = 0; i < uttlist.size(); i++) {
176  std::string utt = uttlist[i];
177  if (!feature_reader.HasKey(utt)) {
178  KALDI_WARN << "Did not find features for utterance " << utt;
179  num_err++;
180  continue;
181  }
182  const Matrix<BaseFloat> &feats = feature_reader.Value(utt);
183  if (!post_reader.HasKey(utt) ||
184  post_reader.Value(utt).size() != feats.NumRows()) {
185  KALDI_WARN << "Did not find posteriors for utterance " << utt
186  << " (or wrong size).";
187  num_err++;
188  continue;
189  }
190  const Posterior &post = post_reader.Value(utt);
191  if (!gselect_reader.HasKey(utt) ||
192  gselect_reader.Value(utt).size() != feats.NumRows()) {
193  KALDI_WARN << "Did not find gselect info for utterance " << utt
194  << " (or wrong size).";
195  num_err++;
196  continue;
197  }
198  const std::vector<std::vector<int32> > &gselect =
199  gselect_reader.Value(utt);
200
201  Matrix<BaseFloat> transformed_feats(feats);
202  for (int32 r = 0; r < transformed_feats.NumRows(); r++) {
203  SubVector<BaseFloat> row(transformed_feats, r);
204  ApplyAffineTransform(fmllr_xform, &row);
205  }
206  AccumulateForUtterance(feats, transformed_feats, gselect,
207  post, trans_model, am_sgmm,
208  logdet, &spk_vars, &spk_stats);
209  num_done++;
210  } // end looping over all utterances of the current speaker
211
212  BaseFloat impr, spk_frame_count;
213  // Compute the FMLLR transform and write it out.
214  spk_stats.Update(am_sgmm, fmllr_globals, fmllr_opts, &fmllr_xform,
215  &spk_frame_count, &impr);
216  fmllr_writer.Write(spk, fmllr_xform);
217  tot_impr += impr;
218  tot_t += spk_frame_count;
219  } // end looping over speakers
220  } else { // per-utterance adaptation
221  SequentialBaseFloatMatrixReader feature_reader(feature_rspecifier);
222  for (; !feature_reader.Done(); feature_reader.Next()) {
223  string utt = feature_reader.Key();
224  const Matrix<BaseFloat> &feats = feature_reader.Value();
225
226  if (!post_reader.HasKey(utt) ||
227  post_reader.Value(utt).size() != feats.NumRows()) {
228  KALDI_WARN << "Did not find posteriors for utterance " << utt
229  << " (or wrong size).";
230  num_err++;
231  continue;
232  }
233  const Posterior &post = post_reader.Value(utt);
234  if (!gselect_reader.HasKey(utt) ||
235  gselect_reader.Value(utt).size() != feats.NumRows()) {
236  KALDI_WARN << "Did not find gselect info for utterance " << utt
237  << " (or wrong size).";
238  num_err++;
239  continue;
240  }
241  const std::vector<std::vector<int32> > &gselect =
242  gselect_reader.Value(utt);
243
244  if (fmllr_reader.IsOpen()) {
245  if (fmllr_reader.HasKey(utt)) {
246  fmllr_xform.CopyFromMat(fmllr_reader.Value(utt));
247  logdet = fmllr_xform.Range(0, dim, 0, dim).LogDet();
248  } else {
249  KALDI_WARN << "Cannot find FMLLR transform for " << utt;
250  fmllr_xform.SetUnit();
251  logdet = 0.0;
252  }
253  } else {
254  fmllr_xform.SetUnit();
255  logdet = 0.0;
256  }
257
258  Matrix<BaseFloat> transformed_feats(feats);
259  for (int32 r = 0; r < transformed_feats.NumRows(); r++) {
260  SubVector<BaseFloat> row(transformed_feats, r);
261  ApplyAffineTransform(fmllr_xform, &row);
262  }
263
264  Sgmm2PerSpkDerivedVars spk_vars;
265  if (spkvecs_reader.IsOpen()) {
266  if (spkvecs_reader.HasKey(utt)) {
267  spk_vars.SetSpeakerVector(spkvecs_reader.Value(utt));
268  am_sgmm.ComputePerSpkDerivedVars(&spk_vars);
269  } else {
270  KALDI_WARN << "Cannot find speaker vector for " << utt;
271  num_err++;
272  continue;
273  }
274  } // else spk_vars is "empty"
275
276  spk_stats.SetZero();
277
278  AccumulateForUtterance(feats, transformed_feats, gselect,
279  post, trans_model, am_sgmm,
280  logdet, &spk_vars, &spk_stats);
281  num_done++;
282
283  BaseFloat impr, spk_frame_count;
284  // Compute the FMLLR transform and write it out.
285  spk_stats.Update(am_sgmm, fmllr_globals, fmllr_opts, &fmllr_xform,
286  &spk_frame_count, &impr);
287  fmllr_writer.Write(utt, fmllr_xform);
288  tot_impr += impr;
289  tot_t += spk_frame_count;
290  }
291  }
292
293  KALDI_LOG << "Done " << num_done << " files, " << num_err << " with errors.";
294  KALDI_LOG << "Overall auxf impr per frame is " << (tot_impr / tot_t)
295  << " per frame, over " << tot_t << " frames.";
296  return (num_done != 0 ? 0 : 1);
297  } catch(const std::exception &e) {
298  std::cerr << e.what();
299  return -1;
300  }
301 }
This code computes Goodness of Pronunciation (GOP) and extracts phone-level pronunciation feature for...
Definition: chain.dox:20
Class for definition of the subspace Gmm acoustic model.
Definition: am-sgmm2.h:231
Class for computing the accumulators needed for the maximum-likelihood estimate of FMLLR transforms f...
Definition: fmllr-sgmm2.h:122
void Read(std::istream &is, bool binary)
Definition: am-sgmm2.cc:89
void AccumulateForUtterance(const Matrix< BaseFloat > &feats, const GaussPost &gpost, const TransitionModel &trans_model, const AmDiagGmm &am_gmm, FmllrDiagGmmAccs *spk_stats)
A templated class for writing objects to an archive or script file; see The Table concept...
Definition: kaldi-table.h:368
kaldi::int32 int32
void Register(OptionsItf *opts)
Definition: fmllr-sgmm2.h:69
void ComputePerSpkDerivedVars(Sgmm2PerSpkDerivedVars *vars) const
Computes the per-speaker derived vars; assumes vars->v_s is already set up.
Definition: am-sgmm2.cc:1369
Allows random access to a collection of objects in an archive or script file; see The Table concept...
Definition: kaldi-table.h:233
bool Update(const AmSgmm2 &model, const Sgmm2FmllrGlobalParams &fmllr_globals, const Sgmm2FmllrConfig &opts, Matrix< BaseFloat > *out_xform, BaseFloat *frame_count, BaseFloat *auxf_improv) const
Computes the FMLLR transform from the accumulated stats, using the pre-transforms in fmllr_globals...
Definition: fmllr-sgmm2.cc:356
int32 FeatureDim() const
Definition: am-sgmm2.h:363
float BaseFloat
Definition: kaldi-types.h:29
std::vector< std::vector< std::pair< int32, BaseFloat > > > Posterior
Posterior is a typedef for storing acoustic-state (actually, transition-id) posteriors over an uttera...
Definition: posterior.h:42
The class ParseOptions is for parsing command-line options; see Parsing command-line options for more...
Definition: parse-options.h:36
void Read(std::istream &in_stream, bool binary)
Definition: fmllr-sgmm2.cc:122
void Read(std::istream &is, bool binary)
A templated class for reading objects sequentially from an archive or script file; see The Table conc...
Definition: kaldi-table.h:287
#define KALDI_ERR
Definition: kaldi-error.h:147
#define KALDI_WARN
Definition: kaldi-error.h:150
Configuration variables needed in the estimation of FMLLR for SGMMs.
Definition: fmllr-sgmm2.h:40
int32 NumGauss() const
Definition: am-sgmm2.h:360
MatrixIndexT NumRows() const
Returns number of rows (or zero for empty matrix).
Definition: kaldi-matrix.h:64
void SetSpeakerVector(const Vector< BaseFloat > &v_s_in)
Definition: am-sgmm2.h:180
Global adaptation parameters.
Definition: fmllr-sgmm2.h:91
void ApplyAffineTransform(const MatrixBase< BaseFloat > &xform, VectorBase< BaseFloat > *vec)
Applies the affine transform &#39;xform&#39; to the vector &#39;vec&#39; and overwrites the contents of &#39;vec&#39;...
#define KALDI_LOG
Definition: kaldi-error.h:153
void Init(int32 dim, int32 num_gaussians)
Definition: fmllr-sgmm2.cc:146
Represents a non-allocating general vector which can be defined as a sub-vector of higher-level vecto...
Definition: kaldi-vector.h:501
